Logosol ES5 / ES8 electric saws

The Logosol electric saws are a perfect choice if you have access to three phase electric. The saws start directly when you press the button and are significantly quieter than a petrol driven chainsaw. Working with your chain sawmill becomes even more efficient.

There are two models of the electric saw, ES5 of 4.6 kW, with a maximum power of up to 12 hp, and the super strong ES8 of 8 kW with a maximum power of 20 hp.

A 16A main fuse is sufficient for all models and they have excellent overheating protection. The smooth running of the engine causes less wear on the chain and the sprocket than with a petrol-driven chainsaw. All models are equipped with an efficient automatic oil pump. There are many different guide bar lengths and chain types to choose from.

We recommend the ES5 when you saw a large amount of normal-sized logs and occasionally some large-diameter logs. The ES8 is suitable when you produce a lot of timber, and when you saw extra hard or oversized timber.

Features

  Traditional guide bars can be used.

  Sawdust shield.

  Integrated chain tensioner.

  Adjustable sliding rails.

  Integrated belt tensioner.

  Low weight.

  Low noise level.

  Compatible with all new and older models of Logosol’s chain sawmills.

Feeding

For our saw units you choose between basic crank feeding or manual remote feeding.

Cutting equipment

Traditional guide bars can be used. Lengths up to 70 cm fit. Logosol has three different guide bar types.

Standard

Guide bar made of three metal plates that are welded together. Low weight, but it is a bit more resilient than a solid bar. Good durability.

Solid

A laser-cut, solid, high-quality guide bar. Milled groove for the chain. Stable and wide bar mount and tough hardening. No nose sprocket.

Premium

In cooperation with the best guide bar manufacturer in the world, the Canadian Cannon Bars, Logosol has developed a fantastic, solid guide bar for log sawing. A thinner material in combination with really tough hardening and precise tolerances in the chain groove, give a bar that is ideal for chain sawmills.

Specification

ES5 Electric Saw (SKU: 6610-000-0005)

Bar length: Recommended guide bar length: 50 or 70 cm. Other lengths are available.
Included: Oil pump, chain tensioner, belt tensioner, and more.
Electrical connection: 3-phase, 400V, 16A maximum power.
Power: 4,6 kW (max. 8 kW)
Weight: 35 kg

ES8 Electric Saw (SKU: 6610-000-0015)

Bar length: Recommended guide bar length: 50 or 70 cm. Other lengths are available.
Included: Oil pump, chain tensioner, belt tensioner, and more.
Electrical connection: 3-phase, 400V, 16A maximum power.
Power: 8 kW (max. 16 kW)
Weight: 40 kg

Optional extras

Bar nose steering (SKU: 6600-001-7005)

You can upgrade your saw unit with the bar-nose steering to get higher precision when making wide cuts. The tube of the bar-nose steering is adjustable and fits 40- 70 cm long guide bars. The guide bar is held in place by a strong magnetic at the bar nose. The bar-nose steering makes it easy to adjust the guide bar parallel to the log beds for a perfect sawing result. Recommended!

Features

  Adjustable for guide bar lengths between 50 and 70 cm.

  Magnetic guide bar holder.

  Adjustable kickback protection.

  Facilitates alignment with the log beds for perfect sawing results.

Crank feed (SKU: 6600-000-7015)

With the convenient basic crank feeding, you follow the saw unit along the sawmill. You crank the saw unit smoothly and easily through the log. The line reel is attached directly to the saw carriage. A line attachment is fitted at the other end of the sawmill. The saw unit is pulled forward with the new and extra strong feed line.

The sturdy crank is vibration-damped and gives a nearly vibration-free grip.

Features

  Sturdy, vibration-damping feeding crank.

  Extra strong feeding line with Dyneema core.

  An affordable option.

  Compatible with electric saws.

Manual remote feeding (SKU: 6600-000-7010)

With the manual remote feeding, you comfortably control the saw unit from one end of the sawmill. You crank the saw unit forward and back through the log and do not have to stand in the middle of exhaust fumes and sawdust spray. In 2020, there will be an addition that will make it possible to use the remote feeding on chainsaws too.

Features

  The crank is adjustable to give you a comfortable and ergonomic working position. You can set it to three different height positions and also adjust it for right-hand or left-hand use.

  Integrated cable tensioner in the pulley.

  Quick attachment for the saw unit.

  The control box (for electric saws) can easily be detached for easy storage when the sawmill is not in use.

  Compatible with electric saws.

Motorized remote feed (SKU: 6600-000-3035)

Logosol motorized remote feed for electric saw

The motorized feed unit makes it comfortable to work with the sawmill and increases production significantly.

A great advantage of the patent-pending friction clutch is that you control the speed of the saw or the log moulder by adjusting the feeding pressure. When the resistance decreases, the speed increases; when the resistance increases, the speed decreases. This puts less stress on the cutting equipment, since the speed is immediately lowered when the chain starts cutting through a knot or swelling in the log. The remote feed unit has an integrated and stable loading ramp that facilitate when installing the electric saw onto the guide rail. With a remote feed unit, the saw brings the board to the operator on the return.

Compatible with the log moulder and all of Logosol’s electric saws. The feed unit can without any problem be used on older sawmill models. With a simple operation, the feed unit can be shifted between the electric saw and the log moulder.

Compatible with all Logosol chain sawmills.

Features

  The speed is automatically adjusted when sawing through the log. This protects the cutting tools from high stress.

✔  Integrated cable tensioner in the pulley.

  The saw unit brings the board to the operator on the return.

  Quick attachment for the saw unit

Logosol F2+ chainsaw mill with ES8 electric saw
