Logosol Big Mill – NEW

Logosol chainsaw Big Mill – Wide Slabber

From oversized log to unique boards with the Logosol Big Mill

New possibilities for giant logs

Giant logs are easiest to cut up on the spot where they were felled. The Logosol Big Mill is a complete equipment package that gives you unique opportunities to make use of valuable giant logs. Cut wide, rough-edged boards from different sorts of fine wood. The system with two guide rails gives stability and highest precision. You work quickly and safely in a comfortable working position. After some practice, you will only need a couple of minutes to set the equipment for the next cut. This sawmill can handle log lengths up to 2.7 metres and diameters up to 135 cm. You can exetend the equipment for longer logs.

Guide rail package for the Big Mill

With the guide rail package for the Big Mill you get highest precision and exact measurements in every saw cut. Very simple adjustments between the saw cuts. Comfortable sawing where you use a crank that gives an even pressure and a very good sawing result. The standard length of the guide rails is 3 metres.

The package consists of a saw frame for big chainsaws and guide rail sections, which give stability and highest precision.

previous arrow
next arrow
Slider

Features and benefits

✔ Comfortable operation with a crank that gives an even pressure and a very good sawing result.

✔ Guide bar lengths of up to 66’’ (167 cm) allow for a cutting width of fully 135 cm. Longer guide bars can be specially ordered.

✔ Safe, efficient and exact sawing.

✔ Simple setting between the saw cuts.

✔ 2.7 metre sawing length with the possibility of extension.

✔ Separate oil pump for lubrication at the bar nose, means minimal wear on the guide bar.

✔ Water cooling of the chain makes the chain stay sharp longer.

✔ Two guide rails give stability and accurate measurements.

✔ Tools for changing chain and templates for exact setting for different board thicknesses are included.

The 3 standard versions:

  • Big Mill to use with a 44” (112cm) bar Maximum cutting width: 80cm
  • Big Mill to use with a 56” (142cm) bar Maximum cutting width: 110cm
  • Big Mill to use with a 66” (167cm) bar Maximum cutting width: 135cm

The maximum width you can cut will be 32cm shorter than the length of the bar. So with a 66” bar you will be able to cut a slab that is maximum 1,35 metres wide.

These guide bars and chains will fit the Stihl MS880 chainsaw.
